Type DC High Voltage, LFP (Lithium Iron Phosphate)
Total Nominal Energy 5.0 kWh
Usable Energy 5.0 kWh
Communication RJ45, CAN (Inverter)
Capacity Extension Modular
Installation Wall mounted, Ground mounted
Enclosure Protection IP66
Dimensions 380 × 170 × 700 mm
Weight 52.0 kg
Product Warranty 10 years
Performance Warranty 70% after 10 years
Packaging:
- 4 piece GoodWe Lynx D battery module LX D5.0-10
- 1 piece GoodWe Lynx D floor bracket
