Sungrow SBR Battery

Type: LiFePO₄, Prismatic Cell
Communication: CAN
Capacity: 9.6 kWh – 25.6 kWh (usable)
Number of Modules: 3 – 8
Nominal Voltage: 192 V
Operating Voltage: 150 – 219 V
Charge / Discharge Current: 30 A (continuous), 42 A (10 s pulse)
Depth of Discharge (DoD): Max. 100 % (adjustable)
Short Circuit Current: 3500 A
Protection Features: Over / Under Voltage, Overcurrent, Over / Under Temperature
DC Protection Switch: Yes
Installation: Indoor / Outdoor, Floor mounted
Cooling: Natural convection
Operating Conditions: Charging 0 – 50 °C / Discharging –20 – 50 °C / Humidity 0–95 % rH (non-condensing)
Enclosure Protection: IP55
Dimensions: (depending on module number)
Weight: (depending on module number)
Product Warranty: 10 years

• Datenblatt DE
